Link Wire-In A Loom, Short 400mm (0LA)
$151.86
Taxes and shipping shown at checkout. Typical delivery is 3 to 7 business days across Canada.
✓ Confirmed-fit parts — add your vehicle in your Garage to check fitment.
A 0.4 m pre-built flying lead for the A plug on Link wire-in ECUs: a factory-terminated SUPERSEAL 1.0 connector at one end and bare wires at the other. The short length is made for patch harnesses, adapters and ECU conversions, and it saves you terminating the ECU plug yourself.
Highlights
- Every position populated, wires colour coded to match Link's wire-in manuals
- Factory-terminated TE Connectivity SUPERSEAL 1.0 A connector
- ECUs with two plugs also need a B loom: the matching 0.4 m B loom is 0LB (101-0003)
- Also made in 2.5 m (2LA) and 5 m (5LA) lengths
- Works for non-Link projects that use the same connector and pin layout
Compatibility
- All G5 wire-in ECUs
- All G4X wire-in ECUs
- G4+ Atom and Atom II, G4+ Monsoon
- G4+ Storm Blue and Storm Black, G4+ Fury, G4+ Xtreme, G4+ Thunder
- G4 Storm, G4 RX, G4 Xtreme
- Vipec V44, i44, V88 and i88
- Not for early G4 (pre-G4+) Atom ECUs
Specifications
- Length: 0.4 m
- Wire: 0.75 mm² (19 AWG) for the red wire at A5 and the black power grounds at A25 and A34; 0.5 mm² (20 AWG) for the rest
- Weight: 140 g
- In the box: 0.4 m A loom with SUPERSEAL 1.0 A connector
