Link Air Temperature Sensor, Bosch-Style Flange Mount (IATB)
$144.56
Taxes and shipping shown at checkout. Typical delivery is 3 to 7 business days across Canada.
✓ Confirmed-fit parts — add your vehicle in your Garage to check fitment.
A fast-response, open-element NTC air temperature sensor with a Bosch-style flange mount. The ECU uses intake air temperature to work out air density and correct fuel and timing as conditions change.
Highlights
- Genuine Facet sensor, NTC thermistor
- Fast-response open element, the type Link recommends for forced induction
- Bosch-style flange mounting
- Bosch-style 2-way connector, terminals and boot included
- Works with all Link ECUs and other aftermarket ECUs with NTC air temperature inputs
- Weld-in bosses sold separately: aluminium (IATBMA) and steel (IATBMS)
Specifications
- Operating range: -40 to +125 °C
- Connector: TE Connectivity JPT/Bosch Jetronic 2-pin
- PC Link calibration: similar to "Link NTC12 & IATB" or "Std Bosch NTC"
- Resistance: 5,500 ohm at 0 °C, 2,420 ohm at 20 °C, 202 ohm at 100 °C
- Weight: 15 g
- In the box: sensor, Bosch-style plug, pin and boot
Install tip: Mount it where it sees true incoming air temperature: upstream of the throttle body and away from heat soak.
